Chevyfazer done did it again...

[Motogiro]

Its not over, I know, but this comes to mind.. .. ..

The Doors - The End :spank::spank:

You had to do this....... I'm having a flash back now n lookin at all the pretty colors floating around the room!


Wait......



[Motogiro]

Chevy, you going to fix it?



[ChevyFazer]

I'm going to give it my best go and see what happens lol



[FinalImpact]

Just some random transmission bits I pulled out of the oil pan including part of a clutch disc....

Looking for suspects... --> parts fische
2004 FZ1 - FZ-1S Yamaha Motorcycle TRANSMISSION Diagram and Parts

2004 FZ1 - FZ-1S Yamaha Motorcycle SHIFT CAM FORK Diagram and Parts #8

2004 FZ1 - FZ-1S Yamaha Motorcycle SHIFT SHAFT Diagram and Parts Pivet on # 7, right side section at the bottom w the shaft?

2004 FZ1 - FZ-1S Yamaha Motorcycle CRANKCASE COVER 1 Diagram and Parts Hmmm.... # 30? Can't tell if its inside or out?



[ChevyFazer]

Part 30 is outside the case its a little clip to hold wires back and that's accounted for so I'm thinking shift forks



[FinalImpact]

Part 30 is outside the case its a little clip to hold wires back and that's accounted for so I'm thinking shift forks

That doesn't look like a shift fork I've ever seen. Although we may not be talking about the same thing???

The clutch is on the other side and I'm guessing nothing obvious was found there other than missing friction. This is perhaps a brace or was secured by that bolt and went into the chopper as a result of chain blasting chunks into the case? IDK

I can't imagine this is hugely different than R6/FZ6 stuff, so that stray chunk of steel seems out of place and I'm curious where it came from and what it does/did!

Did you say it quit shifting at some point? There is this, but I can't imagine thats it....



[ChevyFazer]

The shifter mechanism is all perfectly intact, so that's not it, but looking at it more I don't think its a shift fork after all, I don't have a clue what it is now lol but I'm going to end up splitting the case and fixing everything so I'm sure I will find out what it is in the process



[ChevyFazer]

And the entire transmission locked up shutting the bike down at about 45mph sliding. it still shifted fine but 2nd gear hasn't been right for about a month, it pops out then quickly pops back in gear in 2nd but other than that no shifting issues. Even with the 2nd gear issue it would still shift into and out of 2nd fine



[WarriorDog]

inside the newly found crankcase breather.

That's funny stuff



[ChevyFazer]

Been busy...splitting the case this week end



[yamihoe]

Jesus Travis, STAHP!!!!

less hooning, more commuting! The genesis motor isnt the LS1 of bikes but its not a damn 2.7 chrysler, dont kill it!!!!

MORE PICS! and you have to make it to AMS for the drags, I need to see this thing run again with my own eyes lol



[TownsendsFJR1300]

More engine porn!!!!



[ChevyFazer]

There will be lots more pics to come, and you got it bro, if she runs when I'm done I'm gonna beat it right back down to nothing what better place to do it than the dragstrip



[Motogiro]

More engine porn!!!!

:spank:OMG!!! Look at the Carbs on that one!Blah



[TownsendsFJR1300]

:spank:OMG!!! Look at the Carbs on that one!Blah

Very large vacuum operated slides!!! :thumbup:



[ChevyFazer]

Alright here we go who's ready to hear all the **** I broke!!! Broke a tooth off 1st gear, wore out the dogs on 2ndgear and 3rd gear, bent both shift forks for 1st&2nd and 3rd&4th have 1/3 of a clutch plate inside my oil pickup and smacked a rod bolt and marred up the nut real bad....score me



[TownsendsFJR1300]

So what part actually went thru the case, the rod bolt???

(The drive chain was still on as you did ride it home)...



[ChevyFazer]

Considering its the perfect width of a 530 chain it had to be that, I assume the broke clutch plate of missing tooth on 1st is what caused the initial lock up



[ChevyFazer]

I imagine when the tranny locked up it pushed the chain into the block since I was still rolling and I found 3 broke teeth on the front sprocket



[ChanceCoats123]

That is one hell of a death toll... Now order the replacements and let's see her back in running condition!
