I don't like to reuse gaskets, so when I do mine, I purchase a new:
Valve cover gasket
Timing cover gasket
Water pump drain crush washer
CCT gasket

Also a good time to replace spark plugs if you are so inclined.

You wouldn't happen to have part numbers for those would you :oops:


TownsendsFJR1300

2007 FZ6
Site Supporter
Joined
Feb 7, 2009
Messages
12,516
Reaction score
1,157
Points
113
Location
Cape Coral, Florida, USA
Visit site
You wouldn't happen to have part numbers for those would you :oops:

Don't know your year bike but put in your bike info and you can look up:


.


arronjackson

Member
Joined
Feb 27, 2016
Messages
37
Reaction score
3
Points
8
Location
BC
Visit site
For those looking to do this job in the future the parts you'll need are:

Valve Cover Gasket - 5SL-11193-00-00 - 52 CAD from the dealer
Cam Chain Tensioner Gasket - 4FM-12213-00-00 - $4
Oil Pump Cover Gasket - 5SL-15456-01-00 - $20
Water Pump Crush Washer - 93210-32172 - $7
